Front Terminal Telecom Battery 12v Series
FST (Front Access) Series is especially designed for telecommunication
use with more than 12 years design life in float service.
By combining the newly developed paste formula with up-to-date
AGM structures, this range Front Access connection for fast,
easy installation and maintenance.
Characteristics
>Extreme long life: 12years designed life
>Front terminal: easy to installation
>Excellent deep discharge
>Very low self-discharge
>Short delivery time: 20-25 days
>With IEC, CE, UL, ISO Certificates
>Wide operating temperature range from -15°C to 55°C
>Advanced paste formula with increased recharge efficiency
>Front access terminal with standard width for 19” and 23” ETSI racks
>30% decreased float current lead to excellent high temperature resistance >Thick flat plate with high Tin low Calcium alloy
Applications
· Telecom
· Control Equipments
· UPS systems
· Communication Equipments
· Medical Equipments
· Emergency Power Systems
Model | Nominal Voltage (V) | 10HR Capacity (Ah) | External Dimension | Net Weight | |||
Length | Width | Height | Total Height | ||||
mm | mm | mm | mm | kg(+3%) | |||
FST12-55 | 12 | 55 | 277 | 106 | 223 | 223 | 16.0 |
FST12-80 | 12 | 80 | 562 | 114 | 188 | 188 | 25.0 |
FST12-100 | 12 | 100 | 507 | 110 | 223 | 223 | 29.4 |
FST12-105/110 | 12 | 105/110 | 394 | 110 | 286 | 286 | 30.5 |
FST12-125 | 12 | 125 | 552 | 110 | 239 | 239 | 37.5 |
FST12-150/155 | 12 | 150/155 | 551 | 110 | 288 | 288 | 44.0 |
FST12-160 | 12 | 160 | 551 | 110 | 288 | 288 | 44.5 |
FST12-170/175 | 12 | 170/175 | 546 | 125 | 316 | 316 | 53.5 |
FST12-180 | 12 | 180 | 560 | 125 | 316 | 316 | 54.0 |
FST12-200 | 12 | 200 | 560 | 125 | 316 | 316 | 56.0 |
